Axial Flow Venting Fan

Recommendation index：

Contact consultation
Detailed description

1、Axial Flow Venting Fan

Series DZ-11Axial Flow Venting Fan is taken the design method of low speed and high pressure coefficient.It is a high and energy - saving axial flow fan. DZ-12 is available for special circumstances such as kitchens or plants for exhausting hot wind. DZ-13 could refit as antiseptic and anti-explosion venting fans.

Main Features

1) Low noise

2) Large air volume

3) Power saving

4) Small vibration

5) Nice appearance

Certifications

（1）ISO9001

（2）CE

（3）CCC

Specifications and Parameters

MODE DZ Low Noise Axial Flow Fan

Style	Mode	Machine Number	Power (KW)	REV （r/min)	Air volume （m3/h)	Pressue （Pa)	NoisedB (A)	Weight （KG)
On the wall	DZ-11	2.2C	0.025	1450	400		54	11
		4B	0.25	960	4000		64.6	28
		5A	0.25	720	6000		64	36.5
		5B	0.37	960	7000		70	36.5
		6A	0.55	720	9500		69	46
		7A	1.1	720	15000		72	80
		8A	1.5	720	22000		77	98
Standing	DZ-12	3C	0.06	1450	1600		61.5	18.5
		4B	0.25	960	4000		64.5	23
		5A	0.25	720	6000		64	65
		5B	0.37	960	7000		69	50
		6A	0.55	720	9500		69	55
		6B	1.1	960	14000		77	68.5
		7A	1.1	720	14500		71	93
		7B	2.2	960	22000		78	118
		7C	3	1450	25000		81	110
		8A	1.5	720	23000		77	98
In the pipeline	DZ-13	2.5D	0.37	2800	2000	150	77	10
		3C	0.06	1450	1600	25	61.5	14.5
		3.2D	0.37	2800	3000	160	78.5	18
		4C	0.55	1450	5000	80	69	18.6
		5B	0.37	960	5500	80	70	36.5
		5C	0.75	1450	7000	90	75	43
		6B	1.1	960	10000	100	77.5	79
		6C	2.2	1450	15000	90	80.5	83
		7A	1.1	750	14000	70	72	80
		7B	2.2	960	14000	120	79.5	102
		7C	3	1450	20000	150	81.5	103
		8A	1.5	720	20000	70	76.5	98
		8B	2.2	960	25000	90	80.5	112
		8C	4	1450	28000	100	81.5	122
		10A	3	720	38000	65	81	181
		10B	5.5	960	48500	116	85	196
